VQA3-S24-D15-S - CUI Inc.

VQA3-S24-D15-S Details

• Manufacturer Part Number:

  VQA3-S24-D15-S

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  PACKAGE-7/5

• ECCN Code:

  EAR99

• Manufacturer:

  CUI Inc

• Additional Feature:

  IT ALSO HAS -9 VDC OUPUT

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CUL; EN; IEC; UL

• Efficiency (Main Output):

  82%

• Input Voltage-Max:

  26.4 V

• Input Voltage-Min:

  21.6 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  R-PSMA-P5

• Length:

  19.5 mm

• Line Regulation-Max:

  1.5%

• Load Regulation-Max:

  15%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  5

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.1 A

• Output Voltage-Nom:

  15 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SMA

• Package Equivalence Code:

  MODULE,5LEAD,.6

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.03535 Vrms

• Screening Level:

  IEC/EN/UL 62368-1

• Seated Height-Max:

  13 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Total Power Output-Max:

  1.5 W

• Trim/Adjustable Output:

  NO

• Width:

  9.8 mm
