VS-15ERH02-M3/I - Vishay

VS-15ERH02-M3/I Details

• Manufacturer Part Number:

  VS-15ERH02-M3/I

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN6546A, 8 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  7

• Additional Feature:

  FREE WHEELING DIODE, LOW LEAKAGE CURRENT, LOW POWER LOSS, SNUBBER DIODE

• Application:

  ULTRA FAST RECOVERY

• Breakdown Voltage-Min:

  200 V

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.1 V

• JESD-30 Code:

  R-PDSO-N8

• Non-rep Pk Forward Current-Max:

  264 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  15 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, PLASTIC, 13 INCH

• Rep Pk Reverse Voltage-Max:

  200 V

• Reverse Current-Max:

  1 µA

• Reverse Recovery Time-Max:

  0.028 µs

• Reverse Test Voltage:

  200 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL
