VS-50MT060PHTAPBF - Vishay

VS-50MT060PHTAPBF Details

• Manufacturer Part Number:

  VS-50MT060PHTAPBF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  MODULE-12

• ECCN Code:

  EAR99

• Factory Lead Time:

  20 Weeks

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  5.25

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  121 A

• Collector-Emitter Voltage-Max:

  600 V

• Configuration:

  SERIES CONNECTED, CENTER TAP, 2 ELEMENTS WITH BUILT-IN DIODE AND THERMISTOR

• Gate-Emitter Thr Voltage-Max:

  5.3 V

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-PUFM-P12

• Number of Elements:

  2

• Number of Terminals:

  12

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  305 W

• Reference Standard:

  UL RECOGNIZED

• Surface Mount:

  NO

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UPPER

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON
