The W25Q64FVSFIQ has a minimum of 100,000 erase cycles per sector, and a total of 20,000,000 erase cycles for the entire device.
The HOLD# pin should be pulled high during power-up and power-down to prevent any unwanted commands from being executed. It's recommended to connect a pull-up resistor to VCC.
The recommended clock frequency for the W25Q64FVSFIQ is up to 104 MHz. However, it's recommended to check the specific application requirements and adjust the clock frequency accordingly.
The WP# pin is used to enable or disable write protection for the status register. When WP# is low, the status register is write-protected. When WP# is high, the status register can be written to.
The main difference between the W25Q64FVSFIQ and the W25Q64FVSSIQ is the package type. The W25Q64FVSFIQ is available in a SOIC-8 package, while the W25Q64FVSSIQ is available in a WSON-8 package.
