The recommended PCB land pattern for the WA8759-AL can be found in Coilcraft's application note AN-20, which provides detailed guidelines for pad layout and spacing.
While the datasheet specifies an operating temperature range of -40°C to +125°C, Coilcraft recommends derating the inductor's current rating by 1.5% for every degree above 85°C to ensure reliable operation in high-temperature environments.
Yes, the WA8759-AL is suitable for high-frequency applications up to 10 MHz. However, it's essential to consider the inductor's self-resonant frequency (SRF) and ensure that the operating frequency is below the SRF to maintain optimal performance.
Coilcraft recommends storing the WA8759-AL in a dry, cool place, away from direct sunlight and moisture. Handling should be done with anti-static wrist straps and mats to prevent electrostatic discharge damage.
Yes, Coilcraft recommends using a soldering profile with a peak temperature of 240°C (±5°C) and a dwell time of 3-5 seconds to ensure reliable solder joints. Avoid using excessive soldering temperatures or prolonged exposure to heat.
Trust Checks
This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
WA8759-AL Overview
Use the download button to access the WA8759-AL schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like WA875,
or try a keyword search, such as SMPS Transformers
