WP934SA/3GD - Kingbright

WP934SA/3GD Details

• Manufacturer Part Number:

  WP934SA/3GD

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  ROHS COMPLIANT PACKAGE-6

• Country Of Origin:

  Mainland China

• HTS Code:

  8541.40.20.00

• Manufacturer:

  Kingbright

• YTEOL:

  6

• Additional Feature:

  UL RECOGNIZED, IC COMPATIBLE, HIGH RELIABILITY

• Color:

  GREEN

• Color@Wavelength:

  Green

• Configuration:

  SEPARATE, 3 ELEMENTS

• Forward Current-Max:

  0.025 A

• Forward Voltage-Max:

  2.5 V

• Lens Type:

  DIFFUSED

• Luminous Intensity-Min:

  0.008 cd

• Luminous Intensity-Nom:

  20.0 mcd

• Mounting Feature:

  RADIAL MOUNT

• Number of Functions:

  3

• Number of LEDs in Array:

  3

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Optoelectronic Device Type:

  SINGLE COLOR LED ARRAY

• Overall Height:

  15.24 mm

• Packing Method:

  BULK

• Peak Wavelength:

  565 nm

• Shape:

  ROUND

• Size:

  2.9 mm

• Surface Mount:

  NO

• T-code:

  T-1

• Terminal Finish:

  TIN SILVER COPPER OVER NICKEL

• Terminal Pitch:

  2.54 mm

• Viewing Angle:

  40 deg
