X28HC64J-90T1 - Renesas Electronics

X28HC64J-90T1 Details

• Manufacturer Part Number:

  X28HC64J-90T1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  LCC-32

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Access Time-Max:

  90 ns

• Command User Interface:

  NO

• Data Polling:

  YES

• Data Retention Time-Min:

  100

• Endurance:

  100000 Write/Erase Cycles

• JESD-30 Code:

  R-PQCC-J32

• Length:

  13.97 mm

• Memory Density:

  65536 bit

• Memory IC Type:

  EEPROM

• Memory Width:

  8

• Number of Functions:

  1

• Number of Terminals:

  32

• Number of Words:

  8192 words

• Number of Words Code:

  8000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  70 °C

• Organization:

  8KX8

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QCCJ

• Package Equivalence Code:

  LDCC32,.5X.6

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Page Size:

  64 words

• Parallel/Serial:

  PARALLEL

• Programming Voltage:

  5 V

• Seated Height-Max:

  3.55 mm

• Standby Current-Max:

  0.0002 A

• Supply Current-Max:

  0.04 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  4.5 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  J BEND

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  QUAD

• Toggle Bit:

  YES

• Width:

  11.43 mm

• Write Cycle Time-Max (tWC):

  5 ms
