XC2C64A-7QFG48C - AMD

XC2C64A-7QFG48C Details

• Manufacturer Part Number:

  XC2C64A-7QFG48C

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  7 X 7 MM, 0.50 MM PITCH, LEAD FREE, QFN-48

• Country Of Origin:

  Taiwan

• HTS Code:

  8542.31.00.55

• Manufacturer:

  AMD

• YTEOL:

  0

• Additional Feature:

  REAL DIGITAL DESIGN TECHNOLOGY

• Clock Frequency-Max:

  200 MHz

• In-System Programmable:

  YES

• JESD-30 Code:

  S-XQCC-N48

• JESD-609 Code:

  e3

• JTAG BST:

  YES

• Length:

  7 mm

• Moisture Sensitivity Level:

  3

• Number of I/O Lines:

  37

• Number of Inputs:

  37

• Number of Macro Cells:

  64

• Number of Outputs:

  37

• Number of Terminals:

  48

• Operating Temperature-Max:

  70 °C

• Organization:

  0 DEDICATED INPUTS, 37 I/O

• Output Function:

  MACROCELL

• Package Body Material:

  UNSPECIFIED

• Package Code:

  VQCCN

• Package Equivalence Code:

  LCC48,.27SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, VERY THIN PROFILE

• Peak Reflow Temperature (Cel):

  260

• Programmable Logic Type:

  FLASH PLD

• Propagation Delay:

  7.5 ns

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1 mm

• Supply Voltage-Max:

  1.9 V

• Supply Voltage-Min:

  1.7 V

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  7 mm
