XCAU10P-L1UBVA368I - AMD

XCAU10P-L1UBVA368I Details

• Manufacturer Part Number:

  XCAU10P-L1UBVA368I

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  FCBGA-368

• HTS Code:

  8542.31.00.60

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  AMD

• YTEOL:

  19

• Additional Feature:

  ALSO OPERATES AT 0.85V NOMINAL SUPPLY

• JESD-30 Code:

  R-PBGA-B368

• Length:

  11.5 mm

• Number of CLBs:

  5500

• Number of Inputs:

  128

• Number of Logic Cells:

  96250

• Number of Outputs:

  128

• Number of Terminals:

  368

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  5500 CLBS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA368,18X22,20

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Seated Height-Max:

  0.692 mm

• Supply Voltage-Max:

  0.742 V

• Supply Voltage-Min:

  0.698 V

• Supply Voltage-Nom:

  0.72 V

• Surface Mount:

  YES

• Technology:

  16 nm

• Terminal Finish:

  Tin/Silver/Bismuth/Copper/Nickel (Sn/Ag/Bi/Cu/Ni)

• Terminal Form:

  BALL

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Width:

  9.5 mm
