XCL108B461ER-G - Torex

XCL108B461ER-G Details

• Manufacturer Part Number:

  XCL108B461ER-G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Torex Semiconductor LTD

• YTEOL:

  7

• Analog IC - Other Type:

  AC-DC POWER FACTOR CORRECTION MODULE

• Approvals:

  CE, C-UL-US, PSE, UKCA, UL

• Input Voltage-Max:

  264 V

• Input Voltage-Min:

  90 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-XXMA-X

• Length:

  133.5 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Operating Temperature-Max:

  40 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  5.63 A

• Output Voltage-Max:

  16.8 V

• Output Voltage-Min:

  15.2 V

• Output Voltage-Nom:

  16 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER VOLTAGE, OVER CURRENT, OVER TEMPERATURE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.08484 Vrms

• Screening Level:

  UL 62368-1

• Seated Height-Max:

  34 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  90 W

• Trim/Adjustable Output:

  NO

• Width:

  53.5 mm
