XCR3064XL-10CSG48C - AMD

XCR3064XL-10CSG48C Details

• Manufacturer Part Number:

  XCR3064XL-10CSG48C

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  0.80 MM PITCH, LEAD FREE, CSP-48

• Country Of Origin:

  Taiwan

• HTS Code:

  8542.31.00.55

• Factory Lead Time:

  111 Weeks

• Manufacturer:

  AMD

• YTEOL:

  0

• Additional Feature:

  YES

• Clock Frequency-Max:

  95 MHz

• In-System Programmable:

  YES

• JESD-30 Code:

  S-PBGA-B48

• JESD-609 Code:

  e1

• JTAG BST:

  YES

• Length:

  7 mm

• Moisture Sensitivity Level:

  3

• Number of I/O Lines:

  40

• Number of Inputs:

  40

• Number of Macro Cells:

  64

• Number of Outputs:

  40

• Number of Terminals:

  48

• Operating Temperature-Max:

  70 °C

• Organization:

  0 DEDICATED INPUTS, 40 I/O

• Output Function:

  MACROCELL

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  FBGA

• Package Equivalence Code:

  BGA48,7X7,32

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, FINE PITCH

• Peak Reflow Temperature (Cel):

  260

• Programmable Logic Type:

  EE PLD

• Propagation Delay:

  10 ns

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.8 mm

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  TIN SILVER COPPER

• Terminal Form:

  BALL

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  7 mm
