XCVU11P-2FLGF1924E - AMD

XCVU11P-2FLGF1924E Details

• Manufacturer Part Number:

  XCVU11P-2FLGF1924E

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  BGA-1924

• HTS Code:

  8542.31.00.60

• Manufacturer:

  AMD

• YTEOL:

  10

• JESD-30 Code:

  S-PBGA-B1924

• JESD-609 Code:

  e1

• Length:

  45 mm

• Number of CLBs:

  162000

• Number of Inputs:

  624

• Number of Logic Cells:

  2835000

• Number of Outputs:

  624

• Number of Terminals:

  1924

• Operating Temperature-Max:

  100 °C

• Organization:

  162000 CLBS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Equivalence Code:

  BGA1924,44X44,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Seated Height-Max:

  4.24 mm

• Supply Voltage-Max:

  0.876 V

• Supply Voltage-Min:

  0.825 V

• Supply Voltage-Nom:

  0.85 V

• Surface Mount:

  YES

• Technology:

  16 nm

• Temperature Grade:

  OTHER

• Terminal Finish:

  Tin/Silver/Copper (Sn95.5Ag4.0Cu0.5)

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Width:

  45 mm
