XIO1100ZWSR - Texas Instruments

Description: PCI Interface IC x1 PCI Express PHY 100-NFBGA 0 to 70

Download XIO1100ZWSR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
XIO1100ZWSR - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
XIO1100ZWSR - Texas Instruments PCB footprint - BGA - BGA - ZWS0100A
click to zoom
3D Models
XIO1100ZWSR - Texas Instruments - 3D model - BGA - ZWS0100A
click to zoom

XIO1100ZWSR Details

  • Manufacturer Part Number:

    XIO1100ZWSR

  • Brand Name:

    Texas Instruments

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    BGA-100

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.31.00.30

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    0

  • Bus Compatibility:

    PCI

  • Clock Frequency-Max:

    125 MHz

  • Data Transfer Rate-Max:

    312.5 MBps

  • JESD-30 Code:

    S-PBGA-B100

  • JESD-609 Code:

    e1

  • Length:

    12 mm

  • Moisture Sensitivity Level:

    3

  • Number of Terminals:

    100

  • Operating Temperature-Max:

    70 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    LFBGA

  • Package Equivalence Code:

    BGA100,13X13,32

  • Package Shape:

    SQUARE

  • Package Style:

    GRID ARRAY, LOW PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1.4 mm

  • Supply Voltage-Max:

    1.65 V

  • Supply Voltage-Min:

    1.35 V

  • Supply Voltage-Nom:

    1.5 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    COMMERCIAL

  • Terminal Finish:

    Tin/Silver/Copper (Sn/Ag/Cu)

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.8 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    12 mm

  • uPs/uCs/Peripheral ICs Type:

    BUS CONTROLLER, PCI
