XK372-020.0M - Connor Winfield

XK372-020.0M Details

• Manufacturer Part Number:

  XK372-020.0M

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Manufacturer:

  Connor-Winfield

• YTEOL:

  6.25

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION

• Fall Time-Max:

  8 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  50%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  20 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVCMOS

• Output Load:

  15 pF

• Package Body Material:

  CERAMIC

• Physical Dimension:

  3.2mm x 2.5mm x 1.3mm

• Rise Time-Max:

  8 ns

• Supply Current-Max:

  10 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %
