XTSD04GLGEAG - XTX

Description: LGA8-8x6mm FLASH

Download XTSD04GLGEAG Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
XTSD04GLGEAG - XTX PCB footprint - Small Outline No-lead - Small Outline No-lead - LGA8 (8*6mm)
click to zoom
3D Models
XTSD04GLGEAG - XTX  - 3D model - Small Outline No-lead - LGA8 (8*6mm)
click to zoom

XTSD04GLGEAG Details

  • Manufacturer Part Number:

    XTSD04GLGEAG

  • Part Life Cycle Code:

    Contact Manufacturer

  • Package Description:

    LGA-8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.32.00.51

  • Manufacturer:

    XTX Technology (Shenzhen) Limited

  • JESD-30 Code:

    R-XDSO-N8

  • Memory Density:

    4294967296 bit

  • Memory IC Type:

    FLASH

  • Memory Width:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Number of Words:

    4294967296 words

  • Number of Words Code:

    4000000000

  • Operating Mode:

    ASYNCHRONOUS

  • Organization:

    4GX1

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    SON

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Parallel/Serial:

    SERIAL

  • Programming Voltage:

    2.7 V

  • Supply Voltage-Max (Vsup):

    3.6 V

  • Supply Voltage-Min (Vsup):

    2.7 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL
