YDA138-EZ - Yamaha

YDA138-EZ Details

• Manufacturer Part Number:

  YDA138-EZ

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SSOP

• Package Description:

  LEAD FREE, PLASTIC, SSOP-42

• Pin Count:

  42

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Yamaha LSI

• YTEOL:

  0

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  18 dB

• JESD-30 Code:

  R-PDSO-G42

• Length:

  17.5 mm

• Number of Channels:

  2

• Number of Functions:

  1

• Number of Terminals:

  42

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Power-Nom:

  10 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SSOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, SHRINK PITCH

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2.2 mm

• Supply Voltage-Max (Vsup):

  13.5 V

• Supply Voltage-Min (Vsup):

  9 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  DUAL

• Width:

  8.4 mm
