Z8523016VSG - LITTELFUSE

Z8523016VSG Details

• Manufacturer Part Number:

  Z8523016VSG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  GREEN, PLASTIC, LCC-44

• HTS Code:

  8542.31.00.30

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  0

• Additional Feature:

  MODEM CONTROL I/OS USABLE AS GENERAL PURPOSE I/OS; 10 X 19 FRAME STATUS FIFO

• Boundary Scan:

  NO

• Bus Compatibility:

  Z-BUS

• Clock Frequency-Max:

  16.384 MHz

• Communication Protocol:

  ASYNC, BIT; SYNC, HDLC; SYNC, SDLC; BISYNC

• Data Encoding/Decoding Method:

  NRZ; NRZI; BIPH-MARK(FM1); BIPH-SPACE(FM0); BIPH-LEVEL(MANCHESTER)

• Data Transfer Rate-Max:

  0.512 MBps

• External Data Bus Width:

  8

• JESD-30 Code:

  S-PQCC-J44

• JESD-609 Code:

  e3

• Length:

  16.585 mm

• Low Power Mode:

  NO

• Number of Serial I/Os:

  2

• Number of Terminals:

  44

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QCCJ

• Package Equivalence Code:

  LDCC44,.7SQ

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Qualification Status:

  Not Qualified

• RAM (words):

  0

• Seated Height-Max:

  4.57 mm

• Supply Current-Max:

  15 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  MATTE TIN

• Terminal Form:

  J BEND

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  QUAD

• Width:

  16.585 mm

• uPs/uCs/Peripheral ICs Type:

  SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
