ZTX614 - Diodes Incorporated

ZTX614 Details

• Manufacturer Part Number:

  ZTX614

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Part Package Code:

  TO-92

• Package Description:

  TO-92 COMPATIBLE, E-LINE PACKAGE-3

• Pin Count:

  3

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  1

• Collector Current-Max (IC):

  0.8 A

• Collector-Emitter Voltage-Max:

  100 V

• Configuration:

  DARLINGTON

• DC Current Gain-Min (hFE):

  10000

• JESD-30 Code:

  R-PSIP-W3

• JESD-609 Code:

  e3

• Number of Elements:

  2

• Number of Terminals:

  3

• Operating Temperature-Max:

  200 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  NPN

• Power Dissipation-Max (Abs):

  1 W

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  WIRE

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Element Material:

  SILICON
