1-1634613-0 - TE Connectivity

1-1634613-0 Details

• Manufacturer Part Number:

  1-1634613-0

• Brand Name:

  AMP

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Additional Feature:

  LOW PROFILE

• Body Breadth:

  0.518 inch

• Body Depth:

  0.518 inch

• Body Length:

  0.579 inch

• Body/Shell Style:

  JACK

• Cable Types:

  RG Coax Cable

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF BNC CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Style:

  COAX

• Coupling Type:

  BAYONET

• DIN Conformance:

  NO

• Durability:

  50 Cycles

• EMI Shielded:

  NO

• Empty Shell:

  NO

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulation Resistance:

  5000000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYETHYLENE

• MIL Conformance:

  NO

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Operating Frequency-Max:

  4 GHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  YES

• Shell Finish:

  NICKEL

• Shell Material:

  ZINC ALLOY

• Terminal Length:

  0.169 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1
