10M04SAU169C8G - Intel

10M04SAU169C8G Details

• Manufacturer Part Number:

  10M04SAU169C8G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Country Of Origin:

  Mainland China, Malaysia, Taiwan, USA, Vietnam

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Intel Corporation

• YTEOL:

  7

• Additional Feature:

  ALSO OPERATES AT 3.3 V NOMINAL SUPPLY

• JESD-30 Code:

  S-PBGA-B169

• Length:

  11 mm

• Moisture Sensitivity Level:

  3

• Number of CLBs:

  250

• Number of Inputs:

  246

• Number of Logic Cells:

  4000

• Number of Outputs:

  246

• Number of Terminals:

  169

• Operating Temperature-Max:

  85 °C

• Organization:

  250 CLBS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Equivalence Code:

  BGA169,13X13,32

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Seated Height-Max:

  1.55 mm

• Supply Voltage-Max:

  3.15 V

• Supply Voltage-Min:

  2.85 V

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Technology:

  55 nm

• Temperature Grade:

  OTHER

• Terminal Form:

  BALL

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  BOTTOM

• Width:

  11 mm
