1393215-6 Frequently Asked Questions (FAQs)

• What is the recommended torque value for the screw terminals?
  The recommended torque value for the screw terminals is 0.5-1.5 Nm (4.4-13.3 in-lbs). It's essential to follow this range to ensure reliable connections and prevent damage to the connector.
• Can I use this connector in high-vibration applications?
  Yes, the 1393215-6 connector is designed to withstand vibrations up to 10G (10 Hz to 2000 Hz) according to IEC 61373 Cat. 2. However, it's crucial to ensure proper mounting and secure the connector to the PCB or chassis to maintain reliability.
• What is the operating temperature range for this connector?
  The 1393215-6 connector is rated for operation in temperatures ranging from -40°C to 125°C (-40°F to 257°F). It's essential to consider the temperature range of your application to ensure the connector's reliability and performance.
• Is this connector suitable for use in harsh environments, such as those with high humidity or exposure to chemicals?
  The 1393215-6 connector has a sealed design and is rated IP67, which means it can withstand immersion in water up to 1 meter for 30 minutes. However, it's still important to evaluate the specific environmental conditions of your application and consider additional protection measures if necessary.
• Can I use this connector with wire sizes other than the recommended AWG 20-24?
  While the datasheet recommends using AWG 20-24 wires, it's possible to use other wire sizes with some limitations. Consult with TE Connectivity or a qualified engineer to determine the feasibility of using alternative wire sizes and ensure reliable connections.
