1393258-4 - TE Connectivity

1393258-4 Details

• Manufacturer Part Number:

  1393258-4

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Factory Lead Time:

  20 Weeks, 5 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  8

• Body Breadth:

  12.6 mm

• Body Height:

  25.5 mm

• Body Length or Diameter:

  29 mm

• Coil Current(DC)-Max:

  0.058 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  699 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  206 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  6A@400VAC

• Contact Current(AC)-Max:

  6 A

• Contact Current(DC)-Max:

  6 A

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  400 V

• Contact/Output Supply Type:

  AC

• Dielectric Strength Between Coil and Contacts:

  4000 Vrms

• Dielectric Strength Between Open Contacts:

  1500 Vrms

• End Contact Material:

  SILVER NICKEL

• Input Switching Control Type:

  Random

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  8

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  29mm x 12.6mm x 25.5mm

• Reference Standard:

  CCC; CUL; TUV; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Sealing:

  RT3

• Surface Mount:

  NO

• Terminal Length:

  0.002999745999491999 inch

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  20 g
