477LBA400M2EG - ILLINOIS CAPACITOR

477LBA400M2EG Details

• Manufacturer Part Number:

  477LBA400M2EG

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  ROHS COMPLIANT

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00.40

• Manufacturer:

  Illinois Capacitor Inc

• Capacitance:

  470 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Custom Capabilities:

  Capacitance Tolerance

• Diameter:

  35 mm

• Dielectric Material:

  ALUMINUM (WET)

• ESR:

  529.11 mΩ

• JESD-609 Code:

  e3

• Leakage Current:

  3.76 mA

• Length:

  45 mm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Package Shape:

  CYLINDRICAL PACKAGE

• Package Style:

  Radial

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  400 V

• Ripple Current:

  2230 mA

• Surface Mount:

  NO

• Tan Delta:

  0.15

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Shape:

  SNAP-IN
