556881-2 - TE Connectivity

556881-2 Details

• Manufacturer Part Number:

  556881-2

• Brand Name:

  AMP

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  9 Weeks, 2 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  6.67

• Additional Feature:

  AMPINNERGY, POLARIZED

• Board Mounting Option:

  PEG

• Body Breadth:

  0.76 inch

• Body Depth:

  0.5 inch

• Body Length:

  1.84 inch

• Body/Shell Style:

  RECEPTACLE

• Cable Types:

  STRANDED

• Connector Type:

  RECTANGULAR POWER CONNECTOR

• Contact Arrangement:

  S0P2

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  MALE

• Contact Material:

  NOT APPLICABLE

• Contact Pattern:

  RECTANGULAR

• DIN Conformance:

  NO

• Durability:

  100 Cycles

• EMI Shielded:

  NO

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Force-Max:

  26.688 N

• Insulation Resistance:

  5000000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYPHENYLENE SULFIDE

• MIL Conformance:

  NO

• Mains Connector Rating:

  35A

• Mating Information:

  556879-2

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Option 2:

  LATCHING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  105 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Plating Thickness:

  150u inch

• Polarization Key:

  POLARIZED

• Rated Current (Signal):

  35 A

• Rated Voltage:

  600 V

• Reference Standard:

  CSA, UL

• Terminal Length:

  0.193 inch

• Terminal Pitch:

  11.18 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  2

• UL Flammability Code:

  94V-0

• Withdrawl Force-Min:

  4.448 N
