5962F1820901VYF - Texas Instruments

5962F1820901VYF Details

• Manufacturer Part Number:

  5962F1820901VYF

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  3A001.A.2.C

• HTS Code:

  8542.39.00.30

• Date Of Intro:

  2020-12-02

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Additional Feature:

  Peak-to-peak input voltage range(V) : 0.8

• Analog Input Voltage-Max:

  0.8 V

• Analog Input Voltage-Min:

  -0.8 V

• Converter Type:

  ADC, PROPRIETARY METHOD

• JESD-30 Code:

  S-CBGA-X196

• Length:

  15 mm

• Linearity Error-Max (EL):

  0.07324%

• Number of Analog In Channels:

  2

• Number of Bits:

  12

• Number of Functions:

  1

• Number of Terminals:

  196

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Bit Code:

  OFFSET BINARY, 2S COMPLEMENT BINARY

• Output Format:

  PARALLEL, 8 BITS

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  CGA

• Package Equivalence Code:

  CGA196,14X14,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Qualification Status:

  Qualified

• Sample Rate:

  3200 MHz

• Sample and Hold / Track and Hold:

  TRACK

• Screening Level:

  MIL-PRF-38535 Class V

• Seated Height-Max:

  6.194 mm

• Supply Current-Max:

  1000 mA

• Supply Voltage-Nom:

  1.1 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  MILITARY

• Terminal Form:

  UNSPECIFIED

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Total Dose:

  300k Rad(Si) V

• Width:

  15 mm
