The recommended soldering temperature is 260°C (500°F) with a maximum soldering time of 3 seconds. It's essential to follow the manufacturer's soldering guidelines to prevent damage to the capacitor.
The 941C6P68K-F capacitor is designed to meet the requirements of MIL-PRF-123 and MIL-PRF-39003, which includes vibration testing. However, it's recommended to consult with the manufacturer or a qualified engineer to ensure the capacitor meets the specific vibration requirements of your application.
The ESR of the 941C6P68K-F capacitor is not explicitly stated in the datasheet. However, according to Cornell Dubilier Electronics Inc, the typical ESR for this capacitor is around 0.05 ohms at 100 kHz. For more accurate information, it's recommended to contact the manufacturer or request an application note.
The 941C6P68K-F capacitor is designed to operate up to 85,000 feet (25,908 meters) above sea level. However, it's essential to consult with the manufacturer or a qualified engineer to ensure the capacitor meets the specific requirements of your high-altitude application.
The 941C6P68K-F capacitor is designed to operate in a humid environment, but it's recommended to follow the manufacturer's guidelines for moisture sensitivity. The capacitor should be stored in a dry environment, and any exposure to moisture should be minimized during handling and assembly.
Trust Checks
This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
941C6P68K-F Overview
Use the download button to access the 941C6P68K-F schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like 941C6,
or try a keyword search, such as Film Capacitors
