ACT8846QM468-T15 - Qorvo

ACT8846QM468-T15 Details

• Manufacturer Part Number:

  ACT8846QM468-T15

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Package Description:

  TQFN-48

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  20 Weeks

• Date Of Intro:

  2019-09-11

• Manufacturer:

  Qorvo

• YTEOL:

  1

• Adjustable Threshold:

  YES

• Analog IC - Other Type:

  POWER SUPPLY MANAGEMENT CIRCUIT

• JESD-30 Code:

  S-XQCC-N48

• Length:

  6 mm

• Number of Channels:

  19

• Number of Functions:

  1

• Number of Terminals:

  48

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC48,.24SQ,16

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Seated Height-Max:

  0.8 mm

• Supply Current-Max (Isup):

  12 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  3 V

• Supply Voltage-Nom (Vsup):

  3.6 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  QUAD

• Width:

  6 mm
