AD4080BBCZ-RL7 - Analog Devices

AD4080BBCZ-RL7 Details

• Manufacturer Part Number:

  AD4080BBCZ-RL7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  3A991.c.4

• HTS Code:

  8542.39.00.30

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  9

• Analog Input Voltage-Max:

  3.005 V

• Analog Input Voltage-Min:

  -2.995 V

• Conversion Time-Max:

  0.8 µs

• Converter Type:

  ADC, SUCCESSIVE APPROXIMATION

• JESD-30 Code:

  S-XBGA-B49

• Length:

  5 mm

• Linearity Error-Max (EL):

  0.0008%

• Moisture Sensitivity Level:

  3

• Number of Analog In Channels:

  1

• Number of Bits:

  20

• Number of Functions:

  1

• Number of Terminals:

  49

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  BINARY

• Output Format:

  SERIAL

• Package Body Material:

  UNSPECIFIED

• Package Code:

  LFBGA

• Package Equivalence Code:

  BGA49,7X7,25

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, LOW PROFILE, FINE PITCH

• Sample Rate:

  40 MHz

• Seated Height-Max:

  1.38 mm

• Supply Current-Max:

  35.5 mA

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Terminal Form:

  BALL

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  BOTTOM

• Width:

  5 mm
