AD4129-8BCBZ-RL7 - Analog Devices

AD4129-8BCBZ-RL7 Details

• Manufacturer Part Number:

  AD4129-8BCBZ-RL7

• Brand Name:

  Analog Devices Inc

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  CHIPS W/SOLDER BUMPS/WLCSP

• Package Description:

  WLCSP-35

• Pin Count:

  35

• Manufacturer Package Code:

  CHIPS W/SOLDER BUMPS/WLCSP

• HTS Code:

  8542.39.00.30

• Date Of Intro:

  2023-02-21

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  8.5

• Analog Input Voltage-Max:

  3.6 V

• Analog Input Voltage-Min:

  -3.6 V

• Converter Type:

  ADC, DELTA-SIGMA

• JESD-30 Code:

  R-XBGA-B35

• Length:

  3.56 mm

• Linearity Error-Max (EL):

  0.0015%

• Moisture Sensitivity Level:

  1

• Number of Analog In Channels:

  16

• Number of Bits:

  16

• Number of Functions:

  1

• Number of Terminals:

  35

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  BINARY, OFFSET BINARY

• Output Format:

  SERIAL

• Package Body Material:

  UNSPECIFIED

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA35,5X7,16

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Sample and Hold / Track and Hold:

  SAMPLE

• Seated Height-Max:

  0.56 mm

• Supply Current-Max:

  0.038 mA

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Width:

  2.7 mm
