AD9213BBPZ-10G Details

• Manufacturer Part Number:

  AD9213BBPZ-10G

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  BGA-192

• Pin Count:

  192

• Manufacturer Package Code:

  BP-192-1

• ECCN Code:

  3A001.A.5.A.3

• HTS Code:

  8542.39.00.01

• Date Of Intro:

  2019-08-14

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  8.5

• Analog Input Voltage-Max:

  1.4 V

• Analog Input Voltage-Min:

  -1.4 V

• Conversion Time-Max:

  0.0004 µs

• Converter Type:

  ADC, PROPRIETARY METHOD

• JESD-30 Code:

  S-PBGA-B192

• Length:

  12 mm

• Linearity Error-Max (EL):

  0.1514%

• Moisture Sensitivity Level:

  3

• Number of Analog In Channels:

  1

• Number of Bits:

  12

• Number of Functions:

  1

• Number of Terminals:

  192

• Operating Temperature-Max:

  115 °C

• Operating Temperature-Min:

  -20 °C

• Output Bit Code:

  OFFSET BINARY, 2S COMPLEMENT BINARY, GRAY CODE

• Output Format:

  PARALLEL, WORD

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HBGA

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, HEAT SINK/SLUG

• Sample Rate:

  10250 MHz

• Seated Height-Max:

  1.71 mm

• Supply Current-Max:

  2.24 mA

• Supply Voltage-Nom:

  1 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  OTHER

• Terminal Form:

  BALL

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  BOTTOM

• Width:

  12 mm
