ADAQ4001BBCZ-RL13 - Analog Devices

ADAQ4001BBCZ-RL13 Details

• Manufacturer Part Number:

  ADAQ4001BBCZ-RL13

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CSPBGA-49

• Pin Count:

  49

• Manufacturer Package Code:

  BC-49-5

• HTS Code:

  8542.39.00.30

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  8.5

• Analog Input Voltage-Max:

  12.705 V

• Analog Input Voltage-Min:

  -5.28 V

• Conversion Time-Max:

  0.32 µs

• Converter Type:

  DATA ACQUISITION DEVICE

• JESD-30 Code:

  S-PBGA-B49

• Length:

  7 mm

• Linearity Error-Max (EL):

  0.00119%

• Moisture Sensitivity Level:

  3

• Number of Analog In Channels:

  1

• Number of Bits:

  16

• Number of Functions:

  1

• Number of Terminals:

  49

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  2S COMPLEMENT HEXADECIMAL

• Output Format:

  SERIAL

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  FBGA

• Package Equivalence Code:

  BGA49,7X7,20

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, FINE PITCH

• Peak Reflow Temperature (Cel):

  260

• Sample Rate:

  2 MHz

• Seated Height-Max:

  2.432 mm

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Terminal Form:

  BALL

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  7 mm
