Texas Instruments provides a layout guide and application notes that recommend a star-ground configuration, separate analog and digital grounds, and careful routing of analog and digital signals to minimize noise and interference.
The ADC101S021 does not require calibration, as it has an internal calibration circuit that ensures accurate conversions. However, it's recommended to follow the datasheet's guidelines for power-up sequencing and voltage reference selection to ensure optimal performance.
The ADC101S021 has a maximum sampling rate of 200 kSPS, but this can be affected by the clock frequency, conversion mode, and other factors. Refer to the datasheet's timing diagrams and application notes for more information.
Yes, the ADC101S021 can be used with an external voltage reference, but it must be within the specified range of 1.8V to 3.6V. The external reference must also meet the datasheet's specifications for noise, accuracy, and stability.
The ADC101S021 has built-in error detection and correction mechanisms, such as overflow and underflow flags. Engineers can use these flags to detect and handle errors in their application code. Refer to the datasheet's error handling section for more information.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ADC101S021CISDX/NOPB Overview
Use the download button to access the ADC101S021CISDX/NOPB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADC10,
or try a keyword search, such as Analog to Digital Converters
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
