ADC10D1000CCMLS - Texas Instruments

ADC10D1000CCMLS Details

• Manufacturer Part Number:

  ADC10D1000CCMLS

• Brand Name:

  Texas Instruments

• Part Life Cycle Code:

  Active

• Part Package Code:

  CGA

• Package Description:

  BGA-376

• Pin Count:

  376

• Country Of Origin:

  USA

• ECCN Code:

  3A001.A.2.C

• HTS Code:

  8542.39.00.30

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Additional Feature:

  Peak-to-peak input voltage range(V) : 0.8

• Analog Input Voltage-Max:

  0.8 V

• Analog Input Voltage-Min:

  -0.8 V

• Converter Type:

  ADC, PROPRIETARY METHOD

• JESD-30 Code:

  S-CBGA-B376

• Length:

  27.94 mm

• Linearity Error-Max (EL):

  0.1367%

• Moisture Sensitivity Level:

  1

• Number of Analog In Channels:

  1

• Number of Bits:

  10

• Number of Functions:

  1

• Number of Terminals:

  376

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Bit Code:

  OFFSET BINARY, 2S COMPLEMENT BINARY

• Output Format:

  PARALLEL, WORD

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  BGA

• Package Equivalence Code:

  PGA376(UNSPEC)

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Qualification Status:

  Not Qualified

• Sample Rate:

  2000 MHz

• Sample and Hold / Track and Hold:

  TRACK

• Screening Level:

  MIL-STD-883

• Seated Height-Max:

  3.5 mm

• Supply Voltage-Nom:

  1.9 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  MILITARY

• Terminal Form:

  BALL

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  BOTTOM

• Total Dose:

  100k Rad(Si) V

• Width:

  27.94 mm
