The recommended layout and routing for the ADS131M08IPBS involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing the length of the analog input traces. It's also important to keep the device away from high-frequency noise sources and to use a low-ESR capacitor for the AVDD pin.
To optimize the performance of the ADS131M08IPBS in noisy environments, use a low-pass filter on the analog input, use a shielded cable for the analog input, and consider using a common-mode filter or a differential amplifier to reduce noise. Additionally, ensure that the device is properly grounded and that the power supply is clean and stable.
The maximum sampling rate of the ADS131M08IPBS is 128 kSPS. However, the actual sampling rate may be limited by the system clock frequency, the conversion time, and the settling time of the analog input.
The ADS131M08IPBS does not require calibration. However, it's recommended to perform a system-level calibration to ensure that the device is operating within the specified accuracy. This can be done by applying a known input signal and measuring the output code.
The power consumption of the ADS131M08IPBS depends on the operating mode and the clock frequency. In normal operation, the device consumes around 12 mW at 3.3 V and 1 MSPS. In power-down mode, the device consumes around 10 μW.
