Texas Instruments recommends a 4-layer PCB with a solid ground plane, and to keep analog and digital signals separate. Also, use short and direct traces for the analog inputs, and avoid crossing digital signals over the analog inputs.
Optimization depends on the application. For example, for low-noise applications, use the lowest possible gain and the highest possible sampling rate. For high-speed applications, use the highest possible sampling rate and the lowest possible gain. Consult the datasheet and application notes for more information.
Power up the device in the following sequence: AVDD, DVDD, and then the clock signal. This ensures that the internal voltage regulators are powered up correctly and the device is properly initialized.
The internal voltage regulators require decoupling capacitors to ensure stable operation. Use 1-10uF ceramic capacitors for AVDD and DVDD, and 100nF-1uF capacitors for the analog and digital supplies. Place the capacitors close to the device pins.
Use a high-quality, low-jitter clock source, such as a crystal oscillator or a high-frequency clock generator. The recommended clock frequency is between 2-40MHz, depending on the application and sampling rate requirements.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ADS131M08IRSNR Overview
Use the download button to access the ADS131M08IRSNR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS13,
or try a keyword search, such as Analog to Digital Converters
