The recommended layout and routing for the ADS6243IRGZT involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing the length of the analog input traces. Additionally, it's recommended to use a 4-layer PCB with a dedicated analog power plane and a dedicated digital power plane.
To optimize the performance of the ADS6243IRGZT in a noisy environment, use a low-pass filter at the input, use a shielded cable for the analog input, and consider using a common-mode filter. Additionally, ensure that the analog and digital grounds are properly separated and that the power supply is well-regulated.
The maximum clock frequency that can be used with the ADS6243IRGZT is 50 MHz. However, the actual clock frequency used may be limited by the specific application and the required sampling rate.
To ensure that the ADS6243IRGZT is properly calibrated, follow the calibration procedure outlined in the datasheet, which involves applying a known input voltage and adjusting the offset and gain registers accordingly. Additionally, consider using an external calibration signal source and a precision voltage reference.
The recommended power-up sequence for the ADS6243IRGZT involves powering up the analog power supply (AVDD) first, followed by the digital power supply (DVDD), and then bringing the clock signal high. This ensures that the analog circuitry is properly biased before the digital circuitry is enabled.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ADS6243IRGZT Overview
Use the download button to access the ADS6243IRGZT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS62,
or try a keyword search, such as Analog to Digital Converters
