Texas Instruments recommends a 4-layer PCB with a solid ground plane, and placing the ADC close to the analog signal sources. Additionally, use short and direct traces for the analog inputs, and keep digital signals away from the analog section.
The self-heating effect can cause a temperature rise of up to 10°C above ambient temperature. To minimize its impact, use a heat sink, ensure good airflow, and consider using a thermocouple to monitor the temperature. The self-heating effect can cause a gain error of up to 0.5 LSB/°C, so temperature compensation may be necessary.
Power up the VCC supply first, followed by the VREF supply, and then the digital interface (e.g., SPI or I2C). Ensure that the VCC supply is stable and within the recommended range before applying the VREF supply.
A simple RC filter with a cutoff frequency of 1/3 to 1/2 of the sampling frequency is recommended. Key considerations include the filter's attenuation, phase response, and group delay, as well as the impact of the filter on the signal's amplitude and phase.
The ADS7825UB/1K has a higher sampling rate (250 kSPS vs. 100 kSPS for the ADS7816), lower power consumption (1.5 mW vs. 3.5 mW for the ADS7841), and a more compact package (MSOP-10 vs. SOIC-16 for the ADS7816). The ADS7841 has a higher resolution (16-bit vs. 12-bit for the ADS7825UB/1K) but is also more power-hungry.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ADS7825UB/1K Overview
Use the download button to access the ADS7825UB/1K schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS78,
or try a keyword search, such as Analog to Digital Converters
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
