To minimize noise and ensure accurate conversions, it is recommended to follow a star-grounding scheme, keep analog and digital grounds separate, and use a solid ground plane. Additionally, keep the analog input traces short and away from digital signals, and use a low-impedance power supply.
To optimize performance, ensure that the analog and digital voltage rails are well-regulated and decoupled. Use a low-dropout regulator (LDO) or a switching regulator with a low noise output to power the ADS7957SRHBT. Additionally, use a ferrite bead or a pi-filter to filter out high-frequency noise on the power rails.
The recommended clock frequency for the ADS7957SRHBT is between 10 MHz to 50 MHz. A crystal oscillator or a high-quality clock source with low jitter (<100 ps) is recommended. Avoid using a clock source with high jitter or a clock frequency that is not within the recommended range, as it may affect the ADC's performance.
The ADS7957SRHBT outputs 16-bit data in a serial format. It is recommended to use a FIFO or a buffer to handle the output data, and to use a digital filter (e.g., a moving average filter or a low-pass filter) to remove noise and improve the signal-to-noise ratio (SNR). Additionally, consider using a data processing algorithm that takes into account the ADC's noise floor and non-linearity.
The ADS7957SRHBT has an internal calibration circuit that can be used to trim the ADC's offset and gain errors. It is recommended to perform a full-scale calibration and trimming procedure during the manufacturing process or during system initialization. Refer to the datasheet for the recommended calibration and trimming procedure.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ADS7957SRHBT Overview
Use the download button to access the ADS7957SRHBT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS79,
or try a keyword search, such as Analog to Digital Converters
