Texas Instruments recommends a 4-layer PCB with a solid ground plane, and to keep the analog and digital signals separate. The analog input traces should be short and direct, and the digital output traces should be routed away from the analog inputs. Additionally, decoupling capacitors should be placed close to the device's power pins.
The ADS8345E/2K5 has a built-in POR circuit that resets the device when the power supply voltage rises above 1.5V. The recommended power-up sequence is to apply the analog power supply (AVCC) first, followed by the digital power supply (DVCC), and then the clock signal. This ensures that the device is properly initialized and ready for operation.
The ADS8345E/2K5 can achieve a maximum sampling rate of 100kSPS. However, the actual sampling rate may be limited by the device's settling time, the clock frequency, and the system's noise floor. Additionally, the device's throughput rate may be affected by the conversion mode, the number of channels, and the interface mode.
The ADS8345E/2K5 does not require calibration, as it has an internal calibration circuit that ensures accurate conversions. However, the device's performance may be affected by external factors such as temperature, voltage, and noise. To ensure optimal performance, it is recommended to follow the datasheet's guidelines for PCB layout, component selection, and system design.
The ADS8345E/2K5 has a latency of 2.5 clock cycles, which means that the device requires 2.5 clock cycles to complete a conversion and make the result available on the output pins. This latency should be taken into account when designing the system's timing and synchronization.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ADS8345E/2K5 Overview
Use the download button to access the ADS8345E/2K5 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS83,
or try a keyword search, such as Analog to Digital Converters
