AK2BPDF1-156.2500T - ABRACON

AK2BPDF1-156.2500T Details

• Manufacturer Part Number:

  AK2BPDF1-156.2500T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 6 PIN

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6

• Additional Feature:

  ENABLE/DISABLE FUNCTION; COMPLEMENTARY AND DIFFERENTIAL OUTPUT

• Fall Time-Max:

  0.4 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  25%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  156.25 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVPECL

• Output Load:

  50 OHM

• Package Equivalence Code:

  LCC6,.08X.1,47/37

• Physical Dimension:

  2.5mm x 2.0mm x 1.0mm

• Rise Time-Max:

  0.4 ns

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.375 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %
