AK5DCQ1-200.0000 - ABRACON

AK5DCQ1-200.0000 Details

• Manufacturer Part Number:

  AK5DCQ1-200.0000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 6 PIN

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6

• Additional Feature:

  ENABLE/DISABLE FUNCTION; COMPLEMENTARY OUTPUT

• Fall Time-Max:

  0.5 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  20%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  200 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVDS

• Output Load:

  100 OHM

• Package Equivalence Code:

  SOLCC4,.12

• Packing Method:

  BULK

• Physical Dimension:

  5.0mm x 3.2mm x 1.2mm

• Rise Time-Max:

  0.5 ns

• Supply Current-Max:

  27 mA

• Supply Voltage-Max:

  1.89 V

• Supply Voltage-Min:

  1.71 V

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %
