AM6251ATGGHAALWR - Texas Instruments

AM6251ATGGHAALWR Details

• Manufacturer Part Number:

  AM6251ATGGHAALWR

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  5A992.C

• HTS Code:

  8542.31.00.75

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Additional Feature:

  also available with 0.85 nom supply voltage

• JESD-30 Code:

  S-PBGA-B425

• Length:

  13 mm

• Moisture Sensitivity Level:

  3

• Number of Terminals:

  425

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA425,25X25,20

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Peak Reflow Temperature (Cel):

  250

• Screening Level:

  ISO 26262

• Seated Height-Max:

  0.89 mm

• Supply Voltage-Max:

  0.79 V

• Supply Voltage-Min:

  0.715 V

• Supply Voltage-Nom:

  0.75 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  BALL

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  13 mm

• uPs/uCs/Peripheral ICs Type:

  SOC
