AM62A74AUMHIANFR - Texas Instruments

AM62A74AUMHIANFR Details

• Manufacturer Part Number:

  AM62A74AUMHIANFR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  5A992.C

• HTS Code:

  8542.31.00.50

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• JESD-30 Code:

  S-XBCS-B484

• Length:

  18 mm

• Moisture Sensitivity Level:

  3

• Number of Terminals:

  484

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  CSP

• Package Equivalence Code:

  BGA484,22X22,32

• Package Shape:

  SQUARE

• Package Style:

  CHIP SCALE

• Peak Reflow Temperature (Cel):

  250

• Screening Level:

  AEC-Q100; ISO 26262-ASIL D

• Seated Height-Max:

  1.449 mm

• Supply Voltage-Max:

  0.79 V

• Supply Voltage-Min:

  0.715 V

• Supply Voltage-Nom:

  0.75 V

• Surface Mount:

  YES

• Technology:

  FinFET, 16 nm

• Terminal Form:

  BALL

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  18 mm

• uPs/uCs/Peripheral ICs Type:

  SoC
