AMC3306M25QDWERQ1 - Texas Instruments

AMC3306M25QDWERQ1 Details

• Manufacturer Part Number:

  AMC3306M25QDWERQ1

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Additional Feature:

  Peak-to-peak input voltage range(V) : 250mV

• Analog Input Voltage-Max:

  4.2 V

• Conversion Time-Max:

  0.665 µs

• Converter Type:

  ADC, SUCCESSIVE APPROXIMATION

• JESD-30 Code:

  R-CDFP-F14

• JESD-609 Code:

  e4

• Length:

  9.91 mm

• Linearity Error-Max (EL):

  0.002136%

• Moisture Sensitivity Level:

  3

• Number of Analog In Channels:

  1

• Number of Bits:

  14

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  BINARY

• Output Format:

  SERIAL

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  DFP

• Package Equivalence Code:

  FL14,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  FLATPACK

• Peak Reflow Temperature (Cel):

  260

• Sample Rate:

  21 MHz

• Sample and Hold / Track and Hold:

  SAMPLE

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  2.92 mm

• Supply Current-Max:

  14.5 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  FLAT

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Total Dose:

  75k Rad(Si) V

• Width:

  6.285 mm
