AN7198Z - Panasonic

AN7198Z Details

• Manufacturer Part Number:

  AN7198Z

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  ZFM

• Package Description:

  ZFM-15

• Pin Count:

  15

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  0

• Bandwidth-Nom:

  30 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  34 dB

• Harmonic Distortion:

  10%

• JESD-30 Code:

  R-PZFM-T15

• Number of Channels:

  2

• Number of Functions:

  1

• Number of Terminals:

  15

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Output Power-Nom:

  28 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  250 mA

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  8 V

• Surface Mount:

  NO

• Temperature Grade:

  OTHER

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  ZIG-ZAG
