ASDAIG-32.000MHZ-X-K-S-T - ABRACON

ASDAIG-32.000MHZ-X-K-S-T Details

• Manufacturer Part Number:

  ASDAIG-32.000MHZ-X-K-S-T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 4 PIN

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6

• Additional Feature:

  TS-16949; TRI-STATE; ENABLE/DISABLE FUNCTION

• Fall Time-Max:

  6 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  30%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  32 MHz

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  CMOS

• Output Load:

  15 pF

• Package Body Material:

  CERAMIC

• Packing Method:

  TR, 7 INCH

• Physical Dimension:

  2.5mm x 2.0mm x 0.95mm

• Rise Time-Max:

  6 ns

• Screening Level:

  AEC-Q200

• Supply Current-Max:

  7 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  45/55 %
