ASEMDLC-L-R Frequently Asked Questions (FAQs)

• What is the recommended PCB layout and land pattern for optimal performance?
  Abracon recommends following the IPC-7351B standard for land pattern design and PCB layout. A minimum of 0.5mm clearance between the component and any nearby copper features is recommended to ensure optimal performance and minimize parasitic effects.
• How does the ASEMDLC-L-R handle ESD and surge protection?
  The ASEMDLC-L-R has built-in ESD protection up to 2kV human body model (HBM) and 100V machine model (MM). Additionally, it can withstand surge voltages up to 1kV differential mode and 2kV common mode. However, it's still recommended to follow proper ESD handling and surge protection guidelines during handling and installation.
• What is the operating temperature range for the ASEMDLC-L-R?
  The ASEMDLC-L-R is rated for operation from -40°C to +85°C. However, it's essential to note that the device's performance and accuracy may degrade at extreme temperatures. It's recommended to consult the datasheet and application notes for specific temperature-related considerations.
• Can the ASEMDLC-L-R be used in high-vibration or high-shock environments?
  The ASEMDLC-L-R is designed to withstand moderate levels of vibration and shock. However, it's recommended to consult Abracon's application notes and perform thorough testing to ensure the device meets the specific requirements of your application. Additional mechanical support or mounting may be necessary in extreme environments.
• What is the recommended storage and handling procedure for the ASEMDLC-L-R?
  Abracon recommends storing the ASEMDLC-L-R in its original packaging or a similar ESD-protective container. The device should be handled in an ESD-controlled environment, and operators should wear ESD-protective wrist straps or mats. Avoid exposing the device to extreme temperatures, humidity, or physical stress during storage and handling.
