Abracon recommends a symmetrical PCB layout with a solid ground plane, and the crystal should be placed as close as possible to the microcontroller's oscillator pins. Additionally, the PCB traces should be kept short and shielded to minimize noise and radiation.
The ASEMPLV-156.250MHZ-T is designed to withstand vibration and shock according to the IEC 60068-2-6 and IEC 60068-2-27 standards, respectively. However, it's essential to follow proper mounting and handling procedures to ensure the device's reliability and performance.
The ASEMPLV-156.250MHZ-T is rated for operation up to 125°C, but its frequency stability and accuracy may degrade at higher temperatures. It's recommended to consult with Abracon's application engineers to determine the suitability of the device for specific high-temperature applications.
The ASEMPLV-156.250MHZ-T requires a specific drive level and impedance to operate correctly. It's essential to consult the microcontroller's datasheet and application notes to ensure the oscillator circuit is properly configured and matched to the crystal's requirements.
Abracon recommends storing the ASEMPLV-156.250MHZ-T in its original packaging, away from direct sunlight, moisture, and extreme temperatures. Handling should be done with anti-static wrist straps or mats to prevent electrostatic discharge damage.
