Part Image

B43693C2107Q003 - TDK

Description: Axial-lead/Soldering Star Capacitors, 100?F/250VDC, 16mm dia x 39mm length

Download B43693C2107Q003 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
B43693C2107Q003 - TDK - PCB symbol
click to zoom
PCB Footprints
B43693C2107Q003 - TDK PCB footprint - Capacitors, Polarized Axial Diameter Horizontal Mounting - Capacitors, Polarized Axial Diameter Horizontal Mounting - 16 × 39
click to zoom
3D Models
B43693C2107Q003 - TDK - 3D model - Capacitors, Polarized Axial Diameter Horizontal Mounting - 16 × 39
click to zoom
  • Datasheet Download Datasheet
  • Stock & Prices $ Price & Stock for B43693C2107Q003
  • Part Number B43693C2107Q003
  • Manufacturer TDK
  • Pin Count 2
  • Part Category Capacitor Polarised
  • Package Category Capacitors, Polarized Axial Diameter Horizontal Mounting
  • Footprint Name Capacitors, Polarized Axial Diameter Horizontal Mounting - 16 × 39
  • Released Date Jun 12, 2021
  • Last Modified Date Oct 10, 2023 6:25 AM UTC
  • Pinout / Pin List Click Here (Member Only)

B43693C2107Q003 Details

  • Manufacturer Part Number:

    B43693C2107Q003

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    ,

  • Reach Compliance Code:

    Unknown

  • ECCN Code:

    EAR99

  • Manufacturer:

    TDK Corporation

  • YTEOL:

    0

  • Capacitor Type:

    ALUMINUM ELECTROLYTIC CAPACITOR

  • Number of Terminals:

    2

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

B43693C2107Q003 Overview

Use the download button to access the B43693C2107Q003 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like B4369, or try a keyword search, such as Aluminum Electrolytic Capacitors

About TDK

TDK-Lambda is a global supplier of power supplies and related products. It is a subsidiary of TDK Corporation, a leading electronics company based in Japan. TDK-Lambda specializes in designing and manufacturing a wide range of AC-DC power supplies, DC-DC converters, programmable power supplies, and EMC/EMI filters for various industries and applications.
