BH45B1225 - Holtek

BH45B1225 Details

• Manufacturer Part Number:

  BH45B1225

• Part Life Cycle Code:

  Active

• HTS Code:

  8542.39.00.30

• Manufacturer:

  Holtek Semiconductor Inc

• YTEOL:

  8.08

• Analog Input Voltage-Max:

  5.5 V

• Analog Input Voltage-Min:

  -5.5 V

• Conversion Time-Max:

  0.125 µs

• Converter Type:

  ADC, DELTA-SIGMA

• JESD-30 Code:

  R-PDSO-G8

• Length:

  4.9 mm

• Linearity Error-Max (EL):

  0.0000715%

• Number of Analog In Channels:

  4

• Number of Bits:

  24

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  2'S COMPLEMENT BINARY

• Output Format:

  SERIAL

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP8,.24

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Sample Rate:

  0.16 MHz

• Seated Height-Max:

  1.75 mm

• Supply Current-Max:

  1.5 mA

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  3.9 mm
